VDS-08 Series

Decode IP video streams to analog output Real-time video & audio (30 fps) 4 channels of audio & video (720 x 480) Supports PTZ cameras
Manufacturer: Aventura

Features

  • Decode IP video streams to analog output
  • Real-time video & audio (30 fps)
  • 4 channels of audio & video (720 x 480)
  • Supports PTZ cameras

Specifications

Encoding
Video CompressionH.264 / MPEG4 / MPEG2 / MJPEG
Audio CompressionG.711u
Video bit rate32 Kbps ~ 3072 Kbps, or user defined (Max. 8192 Mbps)
Audio bit rate64 Kbps
Dual StreamSupported
Stream TypeVideo, Video & Audio
External Interface
Network interface1 RJ45 10M/100M/1000M Self-adaptable Ethernet Interface
Serial interface1 RS232 interface, 1 Half-Duplex RS 485 interface for PTZ
Alarm in8 channels
Alarm out2 channels
Audio/Video
Video/Audio Inputs8 Channels (NTSC, PAL System Auto Recognition) CIF BNC (Electrical Level: 1.0Vp-p, Resistance: 75¦¸) Or 1 Channel D1, 4 Channels BNC (Linear Electrical Level, Resistance:600), Microphone jack
Audio Output3.5mm interface (2.0 Vp-p, 1 kΩ)
Video Frame RateNTSC: 30 fps
Pal: 25 fps
Code StreamSingle video stream or composite stream
Communication
Network ProtocolIPv4/v6, HTTP, HTTPS, QoS, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP/RTCP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SOCKSv4/v5, PSIA
Resolution
Video Display ResolutionFULL D1 (720 x 480), CIF (352 x 240), QCIF (176 x 120) resolution
Environment
Operating Temperature14 ~ 131º F (-10 ~ 55º C)
Operating Humidity10 ~ 90%
Electrical
Power Consumption< 22 W
Power SupplyDC 12V
General
Weight8.6 lbs (3.9 kg)
Warranty5 Years

Part Numbers


VDS-08H.264 IP Camera Encoder, 8 Channels Video and Audio, 4CIF
