| Hardware |
| CPU | Intel i7 |
| RAM | 4 GB |
| Video RAM | Up to 4 GB |
| Storage | Up to 24 TB |
| OS | Windows 7 |
| Removable Media | DVD-RW |
| Audio/Video |
| Video Display | 2 HDMI, 2 DisplayPort (On CWS-2DV-RM/CWS-4DV-RM)and 6/8 Display ports on CWS-6DV-RM/CWS-8DV-RM Models |
| Communication |
| LAN | Redundant 10/100/1000 |
| Input Device | 106-Key USB Keyboard / Optical USB Mouse |
| Resolution |
| Video Display Resolution | Analog Up to 4CIF (NTSC: 704X480, PAL: 704×576) Digital Up to 2560 x 1600 |
| Environment |
| Operating Temperature | 25 ~ 110° F (-3.8 ~ 43.3° C) |
| Electrical |
| Power Supply | 500 W / 90 – 264 V |
| General |
| Weight | 50 lbs (22.7 kg) |
| Dimensions | 7″ x 19″ x 20″ (178 x 482 x 508 mm) |
| Chassis Type | 4U Rackmount, 2U Optiona |
| Regulatory Type | CE, FCC, UL |
| Encrypted Watermark | AES / MD5 |
| Safety Standards | EN60950, UL1459 |
| EMC Standards | EN55022 Class-B, EN50082-1 |
| FCC | Part 15 Class-B, VCCI Class-2 |
| Warranty | 5 Years |
